Sentence Examples

  • The siphon is supported on a vertical axle carrying two armatures which are acted upon by two electromagnets.
  • Screw adjustments are provided for closing or opening the air gap between the electromagnets and armatures, for raising or lowering the siphon, and for adjusting the point of the siphon to the centre or side of the paper strip. The received signals are recorded on the paper strip in an undulating continuous line of ink, and are distinguished by the length of deviation from zero.
  • Two receiving instruments, a siphon recorder and a mirror galvanometer, are shown; one only is absolutely necessary, but it is convenient Cable to have the galvanometer ready, so that in case of accident to the recorder it may be at once switched into circuit by the switch s.
  • A fine glass siphon tube is suspended with freedom to move in only one degree, and is connected with the signal-coil and moves with it.
  • The short leg of the siphon tube dips into an insulated ink-bottle, so' that the ink it contains becomes electrified, while the long leg has its open end at a very small distance from a brass table, placed with its surface parallel to the plane in which the mouth of the leg moves, and over which a slip of paper may be passed at a uniform rate, as in the spark recorder.
