Sentence Examples


  • It may be regarded as an epicycloid in which the rolling and fixed circles are equal in diameter, as the inverse of a parabola for its focus, or as the caustic produced by the reflection at a spherical surface of rays emanating from a point on the circumference.
  • The path of contact which it traces is identical with itself; and the flanks of the teeth c are internal and their faces ex ternal epicycloids for wheels, and both flanks and faces are cycloids For a pitch-circle of twice the P, - / radius of the rolling or describing /, -~- circle (as it is called) the internal B ~, epicycloid is a straight line, being, / E in fact, a diameter of the pitch- circle, so that the flanks of the teeth for such a pitch-circle are planes radiating from the axis.
  • Nearly Epicycloidal Teeth: Williss Method.To facilitate the drawing of epicycloidal teeth in practice, Willis showed how to approximate to their figure by means of two circular arcsone concave, for the flank, and the other convex, for the faceand each having for its radius the mean radius of curvature of the epicycloidal arc. \Villiss formulae are founded on the following properties of epicycloids Let R be the radius of the pitch-circle; r that of the describing circle; 8 the angle made by the normal TI to the epicycloid at a given point T, with a tangent-to the circle at Ithat is, the obliquity of the action at T.
  • Then the radius of curvature of the epicycloid at T is For an internal epicycloid, p =4r sin o~1
  • For an external epicycloid, p = 4r sin O~iJ
